Geovision Licencse Plate Recognition Solution

Full integrated and designed purpose for
any traffic related application.

Reliable Capture License Plate during day and night time.

High-speed Capturing or Recognition without motion blur.

Headlight suppression.

Remote Focus and hassle-free Setup mode.

Weather Proof.

Reliable LPR Solution

GeoVision provides License Plate Capturing, LPC and License Plate Recognition, LPR solution for traffic related surveillance application and ensure reliable 24/7 operation. We also provide full integrated Access Control Software for database collection and I/O event control.

Reliable Capture License Plate during

day and night time.

The GV-LPC / LPR cameras are equipped with high-power IR LEDs
and intelligent IR to automatically adjust shutter speed in accordance
to the scene to produce clear crip mega-pixel image even under
low-light conditions.

High-speed Capturing or Recognition without motion blur.

Geovision offers wide range models from 60km (37mph),

120km (75mph) to 200km (124mph) for any type of traffic related applications.

Remote Focus and hassle-free Setup mode.

The Geovision LPC / LPR cameras are equipped with Zoom Lens or motorized Lens

and Setup mode function to make remote focus adjustment easy and friendly.

Headlight suppression.

The Cameras are designed for License Plate Capturing or Recognition with specialized optical
algorithm to avoid impact from headlight of vehicle.

Crisp clear shots are captured despite strong beams of on coming light.

Weather Proof.

The cameras are IP67 rated outdoor-ready housing with built-in

heater and fun for extreme weather conditions.

GeoVision License Plate Recognition Solution

GV - LPC1100

1.3 MP 3x Zoom B/W LPC IP Camera

1.3MP IP Streaming

3x Motorized Varifocal Lens

Built-in power IR Illuminator with

intelligent IR technology

Weatherproof (IP67 rated)

Working temperature:

40°C~50°C(-40°F~122°F)-

Distance cover:

8 ~ 10 m (26.2 ~ 32.8 ft)

GV - LPC1200

1.3 MP 3x Zoom B/W LPC IP Camera

1MP IP Streaming with global shutter

Build-in LPR recognition engine

(GV-LPR1200)

10x AF Zoom Module

Built-in power IR Illuminator

Weatherproof (IP67 rated)

Working temperature:

40°C~50°C(-40°F~122°F)-

Distance cover:

10 ~ 20 m (32.8 ~ 65.6 ft)

GV - LPR1200

Built-in LPR recognition engine

1 MP 10x Zoom B/W All-in-one IP Camera

1MP IP Streaming with global shutter

10x AF Zoom Module
Built-in power IR Illuminator
Weatherproof (IP67 rated)
Working temperature:

-40°C~50°C (-40°F~122°F)
Distance cover:

10 ~ 20 m (32.8 ~ 65.6 ft)

GV - IP LPR Camera 5R

1.3MP 3x Zoom B/WLPC Camera

1.3 MP IP Streaming
3x Motorized Varifocal Lens
Built-in power IR Illuminator

with intelligent

IR technology
Weatherproof (IP67 rated)
Working temperature:

-20°C ~ 50°C
Distance cover:

3 ~ 5 m (9.84 ~ 16.4)

GV - LPC2210

2MP 2.5x Zoom Color LPC Camera

2 MP IP Streaming
2.5x Motorized Varifocal Lens
Built-in power IR Illuminator

with intelligent
IR technology
Weatherproof (IP67 rated)
Working temperature:

-40°C~50°C (-40°F~122°F)
Distance cover:

10 ~ 20 m (32.8 ~ 65.6 ft)

GV - LPC2211

2MP 2.5x Zoom Color LPC Camera

2 MP IP Streaming
2.5x Motorized Varifocal Lens
Built-in power IR Illuminator

with intelligent
IR technology
Weatherproof (IP67 rated)
Working temperature:

-30°C ~ 50°C (-22°F ~ 122°F)
Distance cover:

10 ~ 20 m (32.8 ~ 65.6 ft)

GV - LPC2011

2MP 3 Zoom Color LPC Camera

2 MP IP Streaming
3x Motorized Varifocal Lens
Built-in power IR Illuminator

with intelligent
IR technology
Weatherproof (IP67 rated)
Working temperature:

-30°C ~ 50°C (-22°F ~ 122°F)
Distance cover:

5 ~ 9 m (16.4 ~ 29.6 ft)

Model Name	IP LPR Camera 5R	LPC1100	LPC2210	LPC2211
Product picture
Application	LPC	LPC	LPC	LPC
Image Sensor	1/3" B/W progressive scan CMOS	1/3" B/W progressive scan CMOS	1/2.8" progressive super low lux CMOS	1/2.8" progressive super low lux CMOS
Picture Elements	1280 (H) x 1024 (V)	1280 (H) x 1024 (V)	1920 (H) x 1080 (V)	1920 (H) x 1080 (V)
Camera Type	B/W	B/W	Color	Color
Focal Length	3 ~ 9 mm	9 ~ 22 mm	9 ~ 22 mm	9 ~ 22 mm
Suggested IR Distance of Capture or Recognotion	3 ~ 5 m (9.84 ~ 16.4 ft)	8 ~ 10 m (26.2 ~ 32.8 ft)	10 ~ 20 m (32.8 ~ 65.6 ft)	10 ~ 20 m (32.8 ~ 65.6 ft)
License Plate Type	پلاک بازتابنده	پلاک بازتابنده	پلاک بازتابنده	پلاک بازتابنده
Max. Speed of Vehicle	60 km/h (37 mph)	120 km/h (75 mph)	120 km/h (75 mph)	120 km/h (75 mph)
Power Source	PoE+ (IEEE 802.3at)	DC 48V 2.5A, High PoE (PoE++, 120 W)	DC 48V 2.5A, High PoE (PoE++, 120 W)	DC 12V, PoE (IEEE 802.3af)
Working temperature	20°C ~ 50°C (-4°F ~ 122°F)	-40°C ~ 50°C (-40°F ~ 122°F)	-40°C ~ 50°C (-40°F ~ 122°F)	-30°C ~ 50°C (-22°F ~ 122°F)
Protection	IP67 and IK10 (Metal Casing)	IP67 and IK10 (Metal Casing)	IP67 and IK10 (Metal Casing)	IP67 and IK10 (Metal Casing)

Model Name	LPC2011	LPC1200	LPR1200
Product picture
Application	LPC	LPC	LPR
Image Sensor	1/2.8" progressive super low lux CMOS	Megapixel B/W progressive scan CCD	Megapixel B/W progressive scan CCD
Picture Elements	1920 (H) x 1080 (V)	1280 (H) x 720 (V)	1280 (H) x 720 (V)
Camera Type	Color	B/W	B/W
Focal Length	3 ~ 9 mm	4.7 mm ~ 47 mm	4.7 mm ~ 47 mm
Suggested IR Distance of Capture or Recognotion	5 ~ 9 m (16.4 ~ 29.6 ft)	10 ~ 20 m (32.8 ~ 65.6 ft)	10 ~ 20 m (32.8 ~ 65.6 ft)
License Plate Type	پلاک بازتابنده	پلاک بازتابنده	پلاک بازتابنده
Max. Speed of Vehicle	60 km/h (37 mph)	200 km/h (124.27 mph)	200 km/h (124.27 mph)
Power Source	DC 12V, PoE (IEEE 802.3af)	DC 12V, 5A	DC 12V, 5A
Working temperature	-30°C ~ 50°C (-22°F ~ 122°F)	-40°C ~ 50°C (-40°F ~ 122°F)	-40°C ~ 50°C (-40°F ~ 122°F)
Protection	IP67 and IK10 (Metal Casing)	IP67 and IK10 (Metal Casing)	IP67 and IK10 (Metal Casing)

You can download this file here
